Inspur ultra-slim LED Intelligent All-in-one Machine
The LED Integrated Drive Ultra-Slim Display breaks through the design and technical limitations of traditional all-in-one devices, introducing a highly innovative concept. In terms of appearance, it defies conventions with an extremely slim profile, using advanced processes to highly integrate the drive system with the body. This not only saves space but also creates smooth and elegant product lines, meeting modern users' dual demands for aesthetics and space utilization. Technologically, the fully integrated drive system, developed and optimized through repeated iterations, significantly enhances operational efficiency and achieves deep hardware-software integration. It can rapidly respond to complex commands, delivering a smoother user experience. The module is widely used in various settings such as shopping malls, retail stores, office buildings, residential communities, campuses, hotels, and factories.
Overallthickness12mm,weightbelow10kg/m²,minimumunitsize300*168.75mm.
Commoncathodedrive,maximumpowerconsumption80W/m².
Maximumshippingbrightness1200nits,default800nits.
Supports2Kfull-screenself-loading,requiresnostructuralbrackets,fitsanyinstallationsurface.
Circuit-levelpartitionedpowersupply,energyefficiencyupto95%,stabilityimproved200%,low-carbonandenvironmentallyfriendly.
Whitebalanceagingat30°Cpaneltemperature,operatingtemperaturefullyapproachesroomtemperature.
Greatlyoptimizedinstallationmechanism,measuredinstallationtime<5minperm²,saves100%installationmaterials,reduceslaborby95%,customerscanself-assemble,transportationcostsreducedby80%.
Fullyfloatingconnection,self-adjusting3Dflatness,noriskofinstallationdamage,beginner-friendly.
NationstarLEDs,GOB,dualtop-levelcolorgamutprotection.
ImmersionGoldPCB,ChiponeTop-TierICs,providestopqualityanddisplayregardlessofcost.
Maximum40msingle-columnloadcapacity,unlimitedhorizontalexpansion,supportsirregularshapes,enablesanyindoorLEDscenario.
Ready-to-use,requiresnopre-constructiondesignorstoreclosure,reducesintegratedcostsby30%.
| ProductModel |
LCTHIN12 |
LCTHIN15 |
LCTHIN18 |
| LED&Technology |
Nationstar3-in-1GOBCommonCathode |
||
| PanelThickness(mm) |
12 |
||
| Weight(kg/m²) |
10 |
||
| AverageInstallationTime(min/m²) |
2 |
||
| PixelPitch(mm) |
1.25 |
1.5625 |
1.875 |
| Brightness(cd/m²) |
≥1000 |
||
| RefreshRate(Hz) |
3840Hz/7680HzSelectable |
||
| RearShellMaterial |
Die-CastAluminum |
||
| MaintenanceMethod |
100%FrontMaintenance |
||
| FrontPanelProtectionRating |
IP67 |
||
| PeakPowerConsumption(W/m²) |
≤80 |
||
| AveragePowerConsumption(W/m²) |
≤40 |
||
CommercialRetailStores,ConferenceRooms,HomeEntertainment,ArtandCulturalVenues
